Commissioning
© 2006 ABB STOTZ-KONTAKT GmbH 33
ABB i-bus
®
EIB / KNX
After selecting the option new group address, the associated dialog window
Add group addresses is activated.
Fig. 29: Dialog window: “Time program, Add group addresses”
The main group, middle group and the subgroup are created in sequence via
drag & drop.
Fig. 30: Parameter window: “Time program, Create new main group, middle group and subgroup”
Fig. 31: Dialog window: “Time program, Main group, middle group and subgroup created”
