After selecting the option new group address, the associated dialog window
Add group addresses is activated.
Fig. 67: Dialog window: “Switching time, Add group addresses”
The main group, middle group and the subgroup are created in sequence via
drag & drop.
Fig. 68: Parameter window: “Switching time, Create new main group, middle group and subgroup”
Fig. 69: Parameter window: “Switching time, Main group, middle group and subgroup created”
