Commissioning
© 2006 ABB STOTZ-KONTAKT GmbH 77
ABB i-bus
®
EIB / KNX
After selecting the option new group address, the associated dialog window
Add group addresses is activated.
Fig. 84: Dialog window: “Switching time, Select group address”
New group addresses can be created by dragging & dropping main groups,
middle groups and subgroups.
The Accept button is activated by clicking on the new group address in the
right-hand window.
The new group address is adopted in the following way:
- by double-clicking on the active group address or
- by pressing the right mouse button and selecting Accept in the pop-up
menu or
- by pressing the Accept button.
