NoteAction
WARNING
Used oil is hazardous material and must
be disposed of in a safe way. See Decom-
missioning on page 747 for more informa-
tion.
7
Note
Draining is time-consuming.
Elapsed time varies depending on the
temperature of the oil.
Drain the gearbox oil.8
Remove and clean the pipe after the oil is
drained.
Note
There will be some oil left in the gearbox
after draining.
9
Tightening torque: 10 NmRefit oil plugs.10
Filling oil into the axis-2 gearbox
Use this procedure to refill the gearbox with oil.
Refilling oil to axis-2 gearbox
NoteAction
WARNING
Handling gearbox oil involves several
safety risks, see Gearbox lubricants (oil or
grease) on page 29.
1
CAUTION
The gearbox can contain an excess of
pressure that can be hazardous. Open the
oil plug carefully in order to let the excess
pressure out.
2
Continues on next page
138 Product manual - IRB 1300
3HAC070390-001 Revision: G
© Copyright 2020-2022 ABB. All rights reserved.
4 Maintenance
4.7.3 Changing oil, axis-2 gearbox
Continued
