5.5 Upper and lower arms
5.5.1 Replacing the lower arm
Location of the lower arm
The lower arm is located as shown in the figure.
xx2000001475
Required spare parts
Note
The spare part numbers that are listed in the table can be out of date. See the
latest spare parts of the IRB 1300 via myABB Business Portal,
www.abb.com/myABB.
NoteArticle numberSpare part
Used for IRB 1300-11/0.9.
Used with protection class IP40
and protection type Foundry Plus.
3HAC073073-001Lower arm, short
Used for IRB 1300-11/0.9.
Used with protection class IP67.
3HAC077798-001Lower arm, short, IP67
Used for IRB 1300-11/0.9.
Used with protection type Clean
Room.
3HAC077811-001Lower arm, short, Clean Room
Continues on next page
294 Product manual - IRB 1300
3HAC070390-001 Revision: G
