ABB IRB 1300 - Page 295

NoteArticle numberSpare part
Used for IRB 1300-10/1.15, IRB
1300-7/1.4 and IRB 1300-12/1.4.
Used with protection class IP40
and protection type Foundry Plus.
3HAC073074-001Lower arm, long
Used for IRB 1300-10/1.15, IRB
1300-7/1.4 and IRB 1300-12/1.4.
Used with protection class IP67.
3HAC077799-001Lower arm, long, IP67
Used for IRB 1300-10/1.15, IRB
1300-7/1.4 and IRB 1300-12/1.4.
Used with protection type Clean
Room.
3HAC077812-001Lower arm, long, Clean Room
Used with protection classes IP40
and IP67.
Used with protection type
Foundry Plus.
3HAC073076-001Lower arm support
Used with protection type Clean
Room.
3HAC077813-001Lower arm support, Clean Room
Used for IRB 1300-11/0.9.
Used with protection classes IP40
and IP67.
Used with protection type
Foundry Plus.
3HAC073041-001Swing support, short
Used for IRB 1300-11/0.9.
Used with protection type Clean
Room.
3HAC077808-001Swing support, short, Clean Room
Used for IRB 1300-10/1.15, IRB
1300-7/1.4 and IRB 1300-12/1.4.
Used with protection classes IP40
and IP67.
Used with protection type
Foundry Plus.
3HAC073052-001Swing support, long
Used for IRB 1300-10/1.15, IRB
1300-7/1.4 and IRB 1300-12/1.4.
Used with protection type Clean
Room.
3HAC077810-001Swing support, long, Clean Room
3HAC064977-001Gear unit, axis 2
Used for IRB 1300-11/0.9, IRB
1300-10/1.15 and IRB 1300-7/1.4.
3HAC073078-001Motor unit, axis 2
Used for IRB 1300-12/1.4.3HAC082078-001Motor unit, axis 2 (IRB 1300-12/1.4)
3HAC061327-037O-ring on motor unit
3HAC065676-001Sealing ring, swing support side
3HAC061327-036O-ring on swing
Used for IRB 1300-11/0.9, IRB
1300-10/1.15 and IRB 1300-7/1.4.
3HAC073086-001Motor unit, axis 3
Used for IRB 1300-12/1.4.3HAC082079-001Motor unit, axis 3 (IRB 1300-12/1.4)
Used for IRB 1300-12/1.4.3HAC060261-001Resolver cover on motor (IRB
1300-12/1.4)
3HAC067040-001Timing belt, axis 3
Continues on next page
Product manual - IRB 1300 295
3HAC070390-001 Revision: G
© Copyright 2020-2022 ABB. All rights reserved.
5 Repair
5.5.1 Replacing the lower arm
Continued
