NoteArticle numberSpare part
Replace if damaged.3HAC065651-001Mechanical stop, block A
Used for axis 3 of IRB 1300-
10/1.15.
Replace if damaged.
3HAC065671-001Mechanical stop, block B
3HAC037925-001Magnetic oil plug, G 1/4"
Used with protection classes IP40
and IP67.
Used with protection type
Foundry Plus.
3HAC073306-001Process hub, basic
Used with protection classes IP40
and IP67.
Used with protection type
Foundry Plus.
3HAC073307-001Process hub (CP/CS and air hose,
without Ethernet)
Used with protection classes IP40
and IP67.
Used with protection type
Foundry Plus.
3HAC073308-001Process hub (CP/CS and air hose,
with Ethernet)
Used with protection type Clean
Room.
3HAC077836-001Process hub, basic, Clean Room
Used with protection type Clean
Room.
3HAC077837-001Process hub, Clean Room (CP/CS
and air hose, without Ethernet)
Used with protection type Clean
Room.
3HAC077838-001Process hub, Clean Room (CP/CS
and air hose, with Ethernet)
3HAC067816-001Plastic cable protector, axis 2
3HAC064693-001Plastic cable protector, axis 3
3HAC064694-001Plastic cable protector, axis 4
Used with protection classes IP40
and IP67.
Used with protection type
Foundry Plus.
3HAC073094-001Tubular cover
Used with protection classes IP40
and IP67.
Used with protection type
Foundry Plus.
3HAC073093-001Housing cover
Used with protection classes IP40
and IP67.
Used with protection type
Foundry Plus.
3HAC073092-001Lower arm cover
Used for IRB 1300-11/0.9.
Used with protection classes IP40
and IP67.
Used with protection type
Foundry Plus.
3HAC073095-001Swing cover, short
Used for IRB 1300-10/1.15, IRB
1300-7/1.4 and IRB 1300-12/1.4.
Used with protection classes IP40
and IP67.
Used with protection type
Foundry Plus.
3HAC073096-001Swing cover, long
Continues on next page
296 Product manual - IRB 1300
3HAC070390-001 Revision: G
© Copyright 2020-2022 ABB. All rights reserved.
5 Repair
5.5.1 Replacing the lower arm
Continued
