NoteArticle numberSpare part
Used with IRB 1300-10/1.15.
Used with protection type Clean
Room.
3HAC077830-001Main cable harness, M, basic,
Clean Room
Used with IRB 1300-10/1.15.
Used with protection type Clean
Room.
3HAC077831-001Main cable harness, M, Clean
Room (CP/CS and air hose, without
Ethernet)
Used with IRB 1300-10/1.15.
Used with protection type Clean
Room.
3HAC077832-001Main cable harness, M, Clean
Room (CP/CS and air hose, with
Ethernet)
Used with IRB 1300-7/1.4 and IRB
1300-12/1.4.
Used with protection type Clean
Room.
3HAC077827-001Main cable harness, L, basic, Clean
Room
Used with IRB 1300-7/1.4 and IRB
1300-12/1.4.
Used with protection type Clean
Room.
3HAC077828-001Main cable harness, L, Clean
Room (CP/CS and air hose, without
Ethernet)
Used with IRB 1300-7/1.4 and IRB
1300-12/1.4.
Used with protection type Clean
Room.
3HAC077829-001Main cable harness, L, Clean
Room (CP/CS and air hose, with
Ethernet)
Used with protection type Clean
Room.
3HAC077836-001Process hub, basic, Clean Room
Used with protection type Clean
Room.
3HAC077837-001Process hub, Clean Room (CP/CS
and air hose, without Ethernet)
Used with protection type Clean
Room.
3HAC077838-001Process hub, Clean Room (CP/CS
and air hose, with Ethernet)
3HAC067816-001Plastic cable protector, axis 2
3HAC064693-001Plastic cable protector, axis 3
3HAC064694-001Plastic cable protector, axis 4
Used with protection classes IP40
and IP67.
Used with protection type
Foundry Plus.
3HAC073094-001Tubular cover
Used with protection classes IP40
and IP67.
Used with protection type
Foundry Plus.
3HAC073093-001Housing cover
Used with protection classes IP40
and IP67.
Used with protection type
Foundry Plus.
3HAC073092-001Lower arm cover
Used for IRB 1300-11/0.9.
Used with protection classes IP40
and IP67.
Used with protection type
Foundry Plus.
3HAC073095-001Swing cover, short
Continues on next page
Product manual - IRB 1300 211
3HAC070390-001 Revision: G
© Copyright 2020-2022 ABB. All rights reserved.
5 Repair
5.4.1 Replacing the base
Continued
