NoteAction
xx1400002579
Foundry Plus
Make sure the wrist cover gasket and the
small gasket fitted in the recess of the wrist
cover are undamaged. Replace if damaged.
13
xx1400002580
Foundry Plus
Make sure the washers are fitted in the
gasket holes.
14
Foundry Plus15
Fit the wrist cover, Foundry Plus.
Make sure the gasket stays undamaged
after fitting. Replace if damaged.
xx1400002581
Foundry Plus
Make sure the gasket on the adapter ring is
undamaged. Replace if damaged.
16
Continues on next page
202 Product manual - IRB 6660
3HAC028197-001 Revision: S
© Copyright 2007-2018 ABB. All rights reserved.
4 Repair
4.3.3 Replacement of cable harness, upper end
Continued
