NoteAction
Note
Draining is time-consuming. Elapsed
time depends on the temperature of
the oil.
Open the hose end and drain the oil into a
vessel.
7
Close the oil drain hose, and put it back inside
the base.
8
Refit rear cover by securing it with its attach-
ment screws.
9
Filling oil, axis 1
Use this procedure to fill gearbox axis 1 with oil.
NoteAction
DANGER
Turn off all:
• electric power supply
• hydraulic pressure supply
• air pressure supply
to the robot, before entering the robot working area.
1
WARNING
Handling gearbox oil involves several safety risks.
Before proceeding, please read the safety information
in the section WARNING - Safety risks during work
with gearbox lubricants (oil or grease) on page 50.
2
Shown in figure Location of oil
plugs on page 129.
Open the oil plug, filling.3
Where to find type of oil and
total amount is detailed in Type
and amount of oil in gearboxes
on page 127.
Refill the gearbox with lubricating oil.
The amount of oil to be refilled depends on the
amount that was previously drained. Correct oil level
is detailed in section Inspecting, oil level gearbox
axis 1 on page 104.
4
Tightening torque: 24 Nm.Refit the oil plug, filling.5
3HAC039838-001 Revision: C 131
© Copyright 2013 ABB. All rights reserved.
3 Maintenance
3.4.2 Changing oil, axis-1 gearbox
Continued
