148 Technical data
Ratings
The nominal current ratings for the MicroFlex e190 with 200...240 V AC supply are
given below. For example, if a 6
A model is required to provide brief 300% overloads,
assume its rated current is only 5.3
A.
The DriveSize dimensioning tool available from ABB is recommended for selecting
the drive, motor and gear combination for the required motion profile.
* The maximum overload current between 0 Hz and 2 Hz is 150% of rated current.
Drive type
MFE190-04xx...
PWM
switching
frequency
(Hz)
300%
3 s
overload
(A
rms
)
200%
3 s
overload
(A
rms
)
Low speed
output*
(< 2 Hz)
(A
rms
)
Stationary:
DC output,
any phase
(A)
-01A6-2 8000 1.6 1.6 1.6 2.3
Drive type
MFE190-04xx...
PWM
switching
frequency
(Hz)
300%
3 s
overload
(A
rms
)
200%
3 s
overload
(A
rms
)
Low speed
output*
(< 2 Hz)
(A
rms
)
Stationary:
DC output,
any phase
(A)
-03A0-2 8000 2.5 3.0 3.0 4.2
Drive type
MFE190-04xx...
PWM
switching
frequency
(Hz)
300%
3 s
overload
(A
rms
)
200%
3 s
overload
(A
rms
)
Low speed
output*
(< 2 Hz)
(A
rms
)
Stationary:
DC output,
any phase
(A)
-06A0-2 8000 5.3 6.0 6.0 8.5
Drive type
MFE190-04xx...
PWM
switching
frequency
(Hz)
300%
3 s
overload
(A
rms
)
200%
3 s
overload
(A
rms
)
Low speed
output*
(< 2 Hz)
(A
rms
)
Stationary:
DC output,
any phase
(A)
-09A0-2 8000 7.5 9.0 9.0 12.7
