ABB MicroFlex e190 - Dimensions

Resistor braking 177
 Dimensions
B
A C
G
D
E
F
Part Power
W
Res.
Ω
Dimensions mm (inches)
ABCDEFG
RGJ139 100 39 165
(6.49)
41
(1.61)
22
(0.87)
152
(5.98)
12
(0.47)
10
(0.39)
4.3
(0.17)
RGJ160 100 60 165
(6.49)
41
(1.61)
22
(0.87)
152
(5.98)
12
(0.47)
10
(0.39)
4.3
(0.17)
RGJ260 200 60 165
(6.49)
60
(2.36)
30
(1.18)
146
(5.75)
17
(0.67)
13
(0.51)
5.3
(0.21)
RGJ360 300 60 215
(8.46)
60
(2.36)
30
(1.18)
196
(7.72)
17
(0.67)
13
(0.51)
5.3
(0.21)
