168 Ma
ins filter
s
Specifications and dimensions
G 5.3
mm
H 10.25
mm
F
E
B
D
A
C
G
H
G
H
I
I
Mounting slot detai
l
Dimensions, type OFI-01:
Part
Rated
volts
Rated
amps
@ 40°C
Leakage
current
(mA)
Weig
ht
kg (lbs)
OFI-02
250
8
0.7
0.33 (0.73)
OFI-03
480
7
33
0.5 (1.1)
JFI-02
480
16
33
0.8 (1.76)
OFI-01
250
20
12
0.72 (1.59)
Dimensi
on
OFI-01
Dimensions: mm (in
ches)
A
260 (10.23)
B
73 (2.87)
C
239.5 (9.43)
D
50 (1.97)
E
40 (1.57)
F
21.5 (0.87)
I
M5×10 (0.39) max. depth
167
