Accessories 185
Connectors
The MFE190 DRIVE CONNECTOR KIT (order
code: 3AXD50000038521) containing
terminal blocks for the e190
drive can be provided
separately if necessary
.
The connector pack conta
ins:
No.
Connector
Description
Quantity
1
X1A
1
2
X1B
1
3
X2
1
4
X3
1
5
X4
1
184
186
