162 Technical data
First environment includes domestic premises. It also includes establishments
directly connected without intermediate transformers to a low-voltage network which
supplies buildings used for domestic purposes.
Second environment incl
udes all establishments other than those directly connected
to a low-voltage network which supplies buildings used for domestic purposes.
Drive of category C2.
Power drive system with rated voltage less than 1000 V which
is neither a plug-in device nor a movable device and, when used in the first
environment, is intended to be installed and commissioned only by a professional.
Drive of category C3.
Power drive system with rated voltage less than 1000 V,
intended for use in the second environment and not intended for use in the first
environment.
Drive of category C4.
Power drive system with rated voltage equal to or above
1000 V, or rated current equal to or above 400 A, or intended for use in complex
systems i
n the second environment.
WARNING! The drive can cause radio interference if used in residential or
domestic environment. The user is required to take measures to prevent
interference, in association to the requirements for the CE compliance listed above, if
necessary.
Compliance with EN 61800-3, category C2 & C3
The drive meets the requirements of the EMC
Directive with the following provisions:
1. The drive is equipped with optional mains filter (see page 165).
2. The motor and control cables are sel
ected as specified in the chapter Planning
the electrical installation.
3. The drive is installed according to the in
structions given in this manual.
Motor cable length does not exceed 50 metres (164 ft)
