Electrical installation: AC input / DC input, motor and brake 53
AC power cable connection
Supply cable
Cover bare shield with
insulating tape
Cable cla
mp on bare shie
ld
Cable cla
mp on bare shie
ld
0.5...0.6
N·m (4.4..
.5.3 lbf·i
n)
Motor cable
0.5...0.6
N·m (4.4..
.5.3 lb
f·in)
M4, 10 mm max.
1.0...1.3
N·m (8.9...1
1.5 lbf·in
)
M4, 10 mm max.
1.0...1.3
N·m (8.9...1
1.5 lbf·in
)
Motor earth wire
52
54
