Electrical installation: AC input / DC input, motor and brake 55
Each drive has an independent DC capacitor pre-charging circuit.
~
=
+
–
UDC+ UDC- L2 L3L1
~
=
VWU
MicroFlex e190
Pre-charging circuit
The ratings of the DC connection are given on page 154.
