92 Installation checklist
The supply (input power) voltage matches the drive nominal input voltage.
The supply (input power) is connected to L1/L2/L3 (UDC+/UDC- in case of a DC
supply) and the terminals are tightened to specified torque.
Appropriate supply (input power) fuses and disconnector are installed.
The motor is connected to U/V/W, and the terminals are tightened to specified torque.
The braking resistor (if present) is connected to R- and R+/UDC+, and the terminals
are tightened to specified torque.
The motor cable (and braking resistor cable, if present) is routed away from other
cables.
There are no power factor compensation capacitors in the motor cable.
The external control connections to the control unit are OK.
There are no tools, foreign objects or dust from drilling inside the drive.
The supply (input power) voltage cannot be applied to the output of the drive through
a bypass connection.
Check
