Operation Manual / Power2 850-M / 4.1 Low-pressure stage
Page 37 /
© Copyright 2015 ABB. All rights reserved.
The following tightening torques [Nm] must be observed for the designated screw fittings:
Thread and tightening torque
42087 M12
80 Nm
56017 M8
25 Nm
61037 M16
250 Nm
61037 (nuts that are difficult to access) Pre-tightening torque 60 Nm
Tightening torque angle 90° ±5°
61056 M10
50 Nm
72002 M16
50 Nm
72004 M16
200 Nm
72004 (nuts that are difficult to access) Pre-tightening torque 60 Nm
Tightening torque angle 60° ±5°
70 Nm
77016 M5
5 Nm
77022 M16
200 Nm
Table 17: Tightening torques
