Operation Manual / Power2 850-M / 4.2 High-pressure stage
6 Spare parts / 6.2 View of high-pressure stage with part numbers
© Copyright 2017 ABB. All rights reserved. HZTL4063_EN Revision A August 2017
Part number Designation
01 Cartridge group with hood diffuser and nozzle ring
42001 Bearing casing
42010 (in customer spare part set) O-ring
42012 (in customer spare part set) O-ring
42017 (in customer spare part set) O-ring
42018 (in customer spare part set) O-ring
42099 (in customer spare part set) Socket screw
51001 Gas inlet casing, radial
56017 (in customer spare part set) Hexalobular-head screw
61001 Gas outlet casing
61003 Hexagon-head screw
61004 Verbus Ripp®Locking washer
61009 Hexagon-head screw
61036 Stud
61050 Spiral-wound gasket
61090 (in customer spare part set) Hexagon nut
61300 Support
64001 (in customer spare part set) Lamellar ring
72000 Compressor casing
72003 (in customer spare part set) Washer
72004 (in customer spare part set) Hexagon nut
77000 Wall insert
77040 (in customer spare part set) O-ring
81000 Filter silencer
82000 Air suction branch
82022 Hexagon-head screw
82300 Bellows
86505 / 86515 Speed sensor / connecting cable
Table17: High-pressure stage part numbers
Page 33 / 35
