36 OI/FEP610/FEH610-EN Rev. B | ProcessMaster FEP610, HygienicMaster FEH610
Easy Setup
Pulse Width
30.00 ms
Next Edit
22. Use to call up the edit mode.
23. Use / to set the desired pulse width.
24. Confirm the selection with .
Easy Setup
Damping
30.00 ms
Next Edit
25. Use to call up the edit mode.
26. Use / to set the damping for the volume flow.
27. Confirm the selection with .
Easy Setup
Dig.Out 41 / 42 Mode
Pulse
Next Edit
28. Use to call up the edit mode.
29. Use / to select the desired operating mode (Off,
Logic, Pulse, Frequency) for the digital output.
30. Confirm the selection with .
Easy Setup
Curr.Out at Alarm
High Alarm
Next Edit
31. Use to call up the edit mode.
32. Use / to select the desired alarm mode.
33. Confirm the selection with .
Easy Setup
Low Alarm
3.500 m
A
Next Edit
34. Use to call up the edit mode.
35. Use / to set the alarm current for "Low Alarm".
36. Confirm the selection with .
Easy Setup
High Alarm
21.800 m
A
Next Edit
37. Use to call up the edit mode.
38. Use / to set the alarm current for "High Alarm".
39. Confirm the selection with .
Zero point adjustment of the flowmeter
NOTE
Prior to starting the zero point adjustment, make sure that:
— There is no flow through the sensor (close valves, shut-
off devices etc.).
— The sensor is completely filled with the medium to be
measured
Easy Setup
System Zero
Next OK
— Use to start automatic balancing of the zero point for
the system.
Menu
Easy Setup
Exit Select
Once all parameter have been set, the main menu appears
again. The most important parameters are now set.
40. Use to switch to the process display.
