ProcessMaster FEP610, HygienicMaster FEH610 | OI/FEP610/FEH610-EN Rev. B 87

13.3 Torque information

13.3.1 Torque information for sensors designLevel A

NOTE

The specified torques are valid only for greased threads and piping that is not subject to tensile stress.

ProcessMaster in flange design and HygienicMaster in flange or wafer-type design

Nominal diameter

[mm (inch)]

Nominal pressure

rating

Maximum tightening torque [Nm]

Hard / soft rubber PTFE, PFA, ETFE Ceramic carbide

2) 3) 2) 3) 2) 3)

DN 3 ... 10

(1/10 ... 3/8“

)

PN40 – – 12.43 12.43 – –

PN63/100 – – 12.43 12.43 – –

CL150 – – 12.98 12.98 – –

CL300 – – 17.38 17.38 – –

JIS 10K – – 12.43 12.43 – –

DN 15 (1/2“) PN40 6.74 4.29 14.68 14.68 – –

PN63/100 13.19 11.2 22.75 22.75 – –

CL150 3.65 3.65 12.98 12.98 – –

CL300 4.94 3.86 17.38 17.38 – –

CL600 9.73 9.73 – – – –

JIS 10K 2.84 1.37 14.68 14.68 – –

DN 20 (3/4“) PN40 9.78 7.27 20.75 20.75 – –

PN63/100 24.57 20.42 42.15 42.15 – –

CL150 5.29 5.29 18.49 18.49 – –

CL300 9.77 9.77 33.28 33.28 – –

CL600 15.99 15.99 – – – –

JIS 10K 4.1 1.88 20.75 20.75 – –

DN 25 (1“) PN40 13.32 8.6 13.32 8.6 13.32 8.6

PN63/100 32.09 31.42 53.85 53.85 53.85 53.85

CL150 5.04 2.84 23.98 23.98 23.98 23.98

CL300 17.31 16.42 65.98 38.91 65.98 38.91

CL600 22.11 22.11 – – – –

JIS 10K 8.46 5.56 26.94 26.94 26.94 26.94

DN 32 (1 1/4“) PN40 27.5 15.01 45.08 45.08 45.08 45.08

PN63/100 42.85 41.45 74.19 70.07 74.19 70.07

CL150 4.59 1.98 29.44 29.44 29.44 29.44

CL300 25.61 14.22 45.52 45.52 45.52 45.52

CL600 34.09 34.09 – – – –

JIS 10K 9.62 4.9 45.08 45.08 45.08 45.08

DN 40 (1 1/2“) PN40 30.44 23.71 56.06 56.06 56.06 56.06

PN63/100 62.04 51.45 97.08 97.08 97.08 97.08

CL150 5.82 2.88 36.12 36.12 36.12 36.12

CL300 33.3 18.41 73.99 73.99 73.99 73.99

CL600 23.08 23.08 – – – –

JIS 10K 12.49 6.85 56.06 56.06 56.06 56.06

DN 50 (1 1/2“) PN40 41.26 27.24 71.45 71.45 71.45 71.45

PN63 71.62 60.09 109.9 112.6 109.9 112.6

CL150 22.33 22.33 66.22 66.22 66.22 66.22

CL300 17.4 22.33 38.46 38.46 38.46 38.46

CL600 35.03 35.03 – – – –

JIS 10K 17.27 10.47 71.45 71.45 71.45 71.45

1) Connection flange DIN / EN1092-1 = DN 10 (3/8"), connection flange ASME = DN 15 (1/2").

2) Flange material: steel.

3) Flange material: stainless steel.
