88 OI/FEP610/FEH610-EN Rev. B | ProcessMaster FEP610, HygienicMaster FEH610
Nominal diameter
[mm (inch)]
Nominal pressure
rating
Maximum tightening torque [Nm]
Hard / soft rubber PTFE, PFA, ETFE Ceramic carbide
2) 3) 2) 3) 2) 3)
DN 65 (2 1/2“) PN16 14.94 8 37.02 39.1 37.02 39.1
PN40 30.88 21.11 43.03 44.62 43.03 44.62
PN63 57.89 51.5 81.66 75.72 81.66 75.72
CL150 30.96 30.96 89.93 89.93 89.93 89.93
CL300 38.38 27.04 61.21 61.21 61.21 61.21
CL600 53.91 53.91 – – – –
JIS 10K 14.94 8 37.02 39.1 37.02 39.1
DN 80 (3“) PN40 38.3 26.04 51.9 53.59 51.9 53.59
PN63 63.15 55.22 64.47 80.57 64.47 80.57
CL150 19.46 19.46 104.6 104.6 104.6 104.6
CL300 75.54 26.91 75.54 75.54 75.54 75.54
CL600 84.63 84.63 – – – –
JIS 10K 16.26 9.65 45.07 47.16 45.07 47.16
DN 100 (4“) PN16 20.7 12.22 49.68 78.19 49.68 78.19
PN40 67.77 47.12 78.24 78.19 78.24 78.19
PN63 107.4 95.79 148.5 119.2 148.5 119.2
CL150 17.41 7.82 76.2 76.2 76.2 76.2
CL300 74.9 102.6 102.6 102.6 102.6 102.6
CL600 147.1 147.1 – – – –
JIS 10K 20.7 12.22 49.68 78.19 49.68 78.19
DN 125 (5“) PN16 29.12 18.39 61.4 64.14 61.4 64.14
PN40 108.5 75.81 123.7 109.6 123.7 109.6
PN63 180.3 164.7 242.6 178.2 242.6 178.2
CL150 24.96 11.05 98.05 98.05 98.05 98.05
CL300 81.64 139.4 139.4 139.4 139.4 139.4
CL600 244.1 244.1 – – – –
DN 150 (6“) PN16 46.99 23.7 81.23 85.08 81.23 85.08
PN40 143.5 100.5 162.5 133.5 162.5 133.5
PN63 288.7 269.3 371.3 243.4 371.3 243.4
CL150 30.67 13.65 111.4 111.4 111.4 111.4
CL300 101.4 58.4 123.6 123.6 123.6 123.6
CL600 218.4 218.4 – – – –
DN 200 (8“) PN10 45.57 27.4 113 116.9 113 116.9
PN16 49.38 33.82 70.42 73 70.42 73
PN25 100.6 69.17 109.9 112.5 109.9 112.5
PN40 196.6 144.4 208.6 136.8 208.6 136.8
PN63 350.4 331.8 425.5 282.5 425.5 282.5
CL150 49.84 23.98 158.1 158.1 158.1 158.1
CL300 133.9 78.35 224.3 224.3 224.3 224.3
CL600 391.8 391.8 – – – –
DN 250 (10“) PN10 23.54 27.31 86.06 89.17 86.06 89.17
PN16 88.48 61.71 99.42 103.1 99.42 103.1
PN25 137.4 117.6 166.5 133.9 166.5 133.9
PN40 359.6 275.9 279.9 241 279.9 241
CL150 55.18 27.31 146.1 148.3 146.1 148.3
CL300 202.7 113.2 246.4 246.4 246.4 246.4
2) Flange material: steel.
3) Flange material: stainless steel.
