ProcessMaster FEP610, HygienicMaster FEH610 | OI/FEP610/FEH610-EN Rev. B 53
7.5.4 Menu: Device Setup
Menu / parameter Description
Device Setup
...Access Control Selection of submenu "...Access Control" using .
...Sensor Selection of submenu "...Sensor" using .
...Transmitter Selection of submenu "...Transmitter" using .
Device Setup / ...Access Control
Standard Password Entry / change of the password for the "Standard" access level.
Read Only Switch Indicator of the position of the write protection switch.
For further information, see chapter "Write protection switch" on page 31.
Device Setup / ...Sensor
Range Mode Config Activation of the second measuring range for the mass and volume flow.
The setting can be performed separately for the mass flow rate (Qm) and volume flow (Qv). This means that it is
possible to switch quickly between two measuring ranges (e.g. Qm Max and Qm Max2). Switching is performed via
the parameters "Qm Range Mode", "Qv Range Mode".
— Disabled: Second measuring range for mass and volume flow rate deactivated.
— Qm and Qv: Second measuring range for mass and volume flow rate activated.
— Qm only: Second measuring range for mass flow activated.
— Qv only: Second measuring range for volume flow activated.
Default setting: Disabled
Qm Max DN The value specifies the lower massflow rate a flow velocity of 10 m/s.
The value is set automatically via the selected nominal size multiplied with the density set.
Qm Max 1
Setting of the upper measuring range value 1 (Measuring range = 0 ... Qm Max 1) for the mass flow for forward flow
and reverse flow.
Default setting: 1 x Q
max
DN
Qm Max 2 Setting of the upper measuring range value 2 (Measuring range = 0 ... Qm Max 2) for the mass flow for forward flow
and reverse flow.
This parameter is only available if the value "Max2 active" has been selected for the parameter "Qm Range Mode".
Qm Range Mode Manual switchover between the measuring ranges (Max1 active / Max2 active) for the mass flow measurement. This
parameter is only available if the value Qm only or Qm and Qv has been selected for the parameter "Range Mode
Config".
Qv Max DN The value specifies the lower volume flowrate rate a flow velocity of 10 m/s.
The value is set automatically via the selected nominal size.
Qv Max 1 Setting of the upper measuring range value 1 (Measuring range = 0 ... Qv Max 1) for the volume flow for forward
flow and reverse flow.
Default setting: 1 x Q
max
DN
Qv Max 2 Setting of the upper measuring range value 2 (Measuring range = 0 ... Qv Max 2) for the volume flow for forward
flow and reverse flow.
This parameter is only available if the value "Max2 active" has been selected for the parameter "Qv Range Mode".
Default setting: 1 x Q
max
DN
Qv Range Mode Manual switchover between the measuring ranges (Max1 active / Max2 active) for the volume flow measurement.
This parameter is only available if the value Qv only or Qm and Qv has been selected for the parameter Range
Mode Config".
Sensor Location Tag Entry of the measuring point tag for the sensor.
Alphanumeric, max. 20 characters
Sensor Tag Entry of the TAG number of the sensor.
Alphanumeric, max. 20 characters.
...Operating Mode Selection of submenu "...Operating Mode" using .
