66 OI/FEP610/FEH610-EN Rev. B | ProcessMaster FEP610, HygienicMaster FEH610
Error no. / Range Text on the LCD display Cause Remedy
F086.019 / Electronics Curr.Out 31 / 32 com error.
Defective Board. EMC
disturbance. Call Service.
Defective Motherboard Hardware.
EMC disturbance.
Call Service.
F084.011 / Electronics NV data defect.
Data storage irreparable.
Call Service.
Data in SensorMemory corrupt. Call Service.
F082.014 / Electronics Incompatible Frontend
Board.
Frontend not fit to
Motherboard. Call Service.
Wrong Frontend or Mother Board. Call Service.
F081.026 / Electronics MB voltages outside range.
Defective Motherboard HW.
Call Service.
Defective Mother Board Hardware. Replace Mother Board.
Call Service.
8.2.2 Function check
Error no. / Range Text on the LCD display Cause Remedy
C078.004 / Config. Flowrate to zero.
Check digital in terminals.
The option card Digital Input is configured to
"set flowrate to zero" and this event is
triggered.
Check Digital Input terminals and
configuration.
C076.006 / Config. All totalizer stopp.
Check digital in terminals.
The option card Digital Input is configured to
"All Totalizer stopp" and this event is
triggered.
Check Digital Input terminals and
configuration.
C074.007 / Config.
Totalizer reset.
Reset of one or more
Totalizers.
The option card Digital Input is configured to
"ResetTotalizer" and this event is triggered.
Check Digital Input terminals and
configuration.
C072.003 / Config.
Simulation is on Simulated
values.
Switch off Simulation Mode.
The simulation of a process value or an
output is active.
Switch off simulation mode.
C070.027 / Config.
An alarm is simulated.
Switch off alarm simulation.
The simulation of an alarm is active. Switch alarm simulation to "Off".
8.2.3 Operation outside of specifications (Out Of Spec.)
Error no. / Range Text on the LCD display Cause Remedy
S065.044 / Operation
Inhouse temp. alarm.
Reduce ambient
temperature.
Fluid or ambient temperature is out of spec.
Check proces conditions reduce temperature.
S064.041 / Operation
EPD alarm.
Secure pipe is completely
filled.
Sensor not filled.
Check for empty pipe Make sure sensor is
filled completely.
S062.039 / Operation
Sensor temp. limits alarm.
Change limits or change fluid
temperature.
The fluid temperature is out of Limits.
Check process condition and adjust alarm
limits.
S052.017 / Operation Curr.Out 31 / 32 is
saturated.
CO process value out of
range. Adapt Qmax.
The selected current output 31 / 32 process
value is out of measuring range.
Adapt measuring range.
S047.016 / Operation Pulse output is cut off.
Wrong config. Check pulse
out configuration.
The caluclated output pulse or frequency is
above the configurated limit frequency.
Check pulse out configuration.
