ProcessMaster FEP610, HygienicMaster FEH610 | OI/FEP610/FEH610-EN Rev. B 91
13.3.2 Torque information for sensors Design Level B
NOTE
The specified torques are valid only for greased threads and piping that is not subject to tensile stress.
Nominal diameter
[mm (inch)]
Nominal pressure
rating
Hard / Soft rubber PTFE
2) [Nm] 3) [Nm] 2) [Nm] 3) [Nm]
DN 25 (1“) PN40 — — 13.32 8.6
CL150 — — 23.98 23.98
CL300 — — 65.98 38.91
JIS 10K — — 26.94 26.94
DN 32 (1 1/4“) PN40 — — 45.08 45.08
CL150 — — 29.44 29.44
CL300 — — 45.52 45.52
JIS 10K — — 45.08 45.08
DN 40 (1 1/2“) PN40 — — 56.06 56.06
CL150 — — 36.12 36.12
CL300 — — 73.99 73.99
JIS 10K — — 56.06 56.06
DN 50 (1 1/2“) PN40 — — 71.45 71.45
CL150 — — 66.22 66.22
CL300 — — 38.46 38.46
JIS 10K — — 71.45 71.45
DN 65 (2 1/2“) PN16 — — 37.02 39.1
PN40 — — 43.03 44.62
CL150 — — 89.93 89.93
CL300 — — 61.21 61.21
JIS 10K — — 37.02 39.1
DN 80 (3“) PN40 — — 51.9 53.59
CL150 — — 104.6 104.6
CL300 — — 75.54 75.54
JIS 10K — — 45.07 47.16
DN 100 (4“) PN16 — — 49.68 78.19
PN40 — — 78.24 78.19
CL150 — — 76.2 76.2
CL300 — — 102.6 102.6
JIS 10K — — 49.68 78.19
DN 125 (5“) PN16 — — 61.4 64.14
PN40 — — 123.7 109.6
CL150 — — 98.05 98.05
CL300 — — 139.4 139.4
DN 150 (6“) PN16 — — 81.23 85.08
PN40 — — 162.5 133.5
CL300 — — 111.4 111.4
DN 200 (8“) PN10 — — 123.6 123.6
PN16 — — 113 116.9
PN25 — — 70.42 73
PN40 — — 109.9 112.5
CL150 — — 208.6 136.8
CL300 — — 158.1 158.1
2) Flange material: steel.
3) Flange material: stainless steel.
