90 OI/FEP610/FEH610-EN Rev. B | ProcessMaster FEP610, HygienicMaster FEH610

Nominal diameter

[mm (inch)]

Nominal pressure

rating

Maximum tightening torque [Nm]

Hard / soft rubber PTFE, PFA, ETFE Ceramic carbide

2) 3) 2) 3) 2) 3)

DN 1000 (40“) PN10 541.3 419.2 On request On request 541.3 419.2

PN16 955.5 756.1 On request On request 955.5 756.1

PN25 2006 1612 On request On request 2006 1612

CL150 654.2 598.8 650.6 385.1 654.2 598.8

CL300 2181 On request On request On request 2181 On request

DN 1100 (44“) CL150 749.1 682.6 741.3 345.9 – –

CL300 2607 On request On request On request – –

DN 1200 (48“) PN 6 363.5 On request – – – –

PN10 705.9 On request – – – –

PN16 1464 On request – – – –

CL150 815.3 731.6 – – – –

CL300 3300 On request – – – –

DN 1350 (54“) CL150 1036 983.7 – – – –

CL300 5624 On request – – – –

DN 1400 (56“) PN 6 515 On request – – – –

PN10 956.3 On request – – – –

PN16 1558 On request – – – –

DN 1500 (60“) CL150 1284 1166 – – – –

CL300 6139 On request – – – –

DN 1600 (64“) PN 6 570.7 On request – – – –

PN10 1215 On request – – – –

PN16 2171 On request – – – –

DN 1800 (72“) PN 6 708.2 On request – – – –

PN10 1492 On request – – – –

PN16 2398 On request – – – –

DN 2000 (80“) PN 6 857.9 On request – – – –

PN10 1840 On request – – – –

PN16 2860 On request – – – –

2) Flange material: steel.

3) Flange material: stainless steel.
