ABB ProcessMaster FEP611 User Manual

84 OI/FEP610/FEH610-EN Rev. B | ProcessMaster FEP610, HygienicMaster FEH610
12.5 HygienicMaster - Material loads for process
connections
The limits for the permissible measuring medium temperature
(T
medium
) and permissible pressure (P
medium
) are calculated on
the basis of the lining and flange material used in the device
(refer to the name plate on the device).
Minimum permissible operating pressure
The following tables show the minimum permissible operating
pressure (P
medium
) depending on measuring medium
temperature (T
medium
) and the liner material.
Liner material Nominal
diameter
P
medium
[mbar abs]
T
medium
1)
PFA DN 3 ... 100
(1/10 ... 4")
0 < 130 °C (266 °F)
1) For CIP/SIP cleaning, higher temperatures are permitted for limited time
periods; refer to the chapter "Maximum permissible cleaning temperature" on
page 83.
Liner approvals on request; please contact ABB.
Overview - Material load
Process
connection
DN P
medium
max. T
medium
Wafer type DN 3 ... 50
(1/10 ... 2“)
40 bar (580 psi) -25 ... 130 °C
(-13 ... 266 °F)
DN 65 ... 100
(2 1/2 ... 4“)
16 bar (232 psi)
Welded spuds
DIN 2463,
ISO 1127,
DIN 11850
DN 3 ... 40
(1/10 ... 1 1/2“)
40 bar (580 psi) -25 ... 130 °C
(-13 ... 266 °F)
DN 50, DN 80
(2“, 3“)
16 bar (232 psi)
DN 65, DN 100
(2 1/2“, 4“)
10 bar (145 psi)
Welded spuds
SMS 1145
DN 25,
DN 40 ... 100
(1“,1,5 ... 4“)
6 bar (87 psi) -25 ... 130 °C
(-13 ... 266 °F)
Threaded pipe
connection
DIN 11851
DN 3 ... 40
(1/10 ... 1 1/2“)
40 bar (580 psi) -25 ... 130 °C
(-13 ... 266 °F)
DN 50, DN 80
(2“, 3“)
16 bar (232 psi)
DN 65, DN 100
(2 1/2“, 4“)
10 bar (145 psi)
Tri-Clamp
DIN 32676
DN 3 ... 50
(1/10 ... 2“)
16 bar (232 psi) -25 ... 130 °C
(-13 ... 266 °F)
DN 65 ... 100
(2 1/2 ... 4“)
10 bar (145 psi)
Tri-Clamp
ASME BPE
DN 3 ... 80
(1/10 ... 3“)
10 bar (145 psi) -25 ... 121 °C
(-13 ... 250 °F)
DN 100 (4") 8.6 bar
(124.7 psi)
External thread
ISO 228,
DIN 2999
DN 3 ... 25
(1/10 ... 1“)
16 bar (232 psi) -25 ... 130 °C
(-13 ... 266 °F)
Welded spuds
OD tubing
DN 3 ... 50
(1/10 ... 2“)
10 bar (145 psi) -25 ... 130 °C
(-13 ... 266 °F)
