92 OI/FEP610/FEH610-EN Rev. B | ProcessMaster FEP610, HygienicMaster FEH610
Nominal diameter
[mm (inch)]
Nominal pressure
rating
Hard / Soft rubber PTFE
2) [Nm] 3) [Nm] 2) [Nm] 3) [Nm]
DN 250 (10“) PN10 — — 86.06 89.17
PN16 — — 99.42 103.1
PN25 — — 166.5 133.9
PN40 — — 279.9 241
CL150 — — 146.1 148.3
CL300 — — 246.4 246.4
DN 300 (12“) PN10 — — 91.29 94.65
PN16 — — 113.9 114.8
PN25 — — 151.1 106.9
PN40 — — 254.6 252.7
CL150 — — 203.5 198
CL300 — — 421.7 259.1
DN 350 (14“) PN10 — — 72.49 75.22
PN16 — — 124.9 104.4
PN25 — — 226.9 167.9
CL150 — — 270.5 263
CL300 — — 463.9 259.4
DN 400 (16“) PN10 — — 120.1 113.9
PN16 — — 191.4 153.8
PN25 — — 404 246.7
CL150 — — 229.3 222.8
CL300 — — 635.8 328.1
DN 450 (18“) CL150 — — 267.3 192.3
CL300 — — 660.9 300
DN 500 (20“) PN10 — — 153.9 103.5
PN16 — — 312.1 224.8
PN25 — — 477.1 286
CL150 — — 237.3 230.4
CL300 — — 786.8 363.1
DN 600 (24“) PN10 — — 238.7 149.1
PN16 — — 496.7 365.3
PN25 — — 750.7 539.2
CL150 — — 451.6 305.8
CL300 — — 1376 587.4
2) Flange material: steel.
3) Flange material: stainless steel.
Torque information for HygienicMaster with variable process connections
Nominal diameter Max. tightening torque
[mm] [inch] [Nm]
DN 3 ... 10 3/8“ 8
DN 15 1/2“ 10
DN 20 3/4“ 21
DN 25 1 31
DN 32 1 1/4“ 60
DN 40 1 1/2“ 80
DN 50 2 5
DN 65 2 1/2“ 5
DN 80 3 15
DN 100 4 14
