ProcessMaster FEP610, HygienicMaster FEH610 | OI/FEP610/FEH610-EN Rev. B 59
Menu / parameter Description
Input/Output / Dig.Out 41 / 42 / ...Setup Logic Output
Logic Output Action
Selection of binary output function.
— Off: The binary output is deactivated.
— F/R Signal: The binary output indicates the flow direction.
— Alarm Signal: The binary output indicates an active alarm. The alarm is selected in the "...Alarm Config" menu.
— Dual Range: The binary output is activated when measuring range 2 (Qm Max 2 / Qv Max 2) is selected. This
selection is only available if the parameter "Dual Range" has been configured to Qm or Qv.
Active Mode Select switching properties for the binary output.
— Active High: Normally open.
— Active Low: Normally closed.
Default setting: Active High.
Input/Output / Dig.Out 41 / 42- / ...Alarm Config
General Alarm
Select error messages signaled via the binary output 41 / 42.
Only if the parameter "Logic Output Action" is set to Alarm Signal.
Default setting: Off.
Qv Volumeflow Max
Qv Volumeflow Min
EPD
Input/Output / Dig.Out 51 / 52
Mode Selection of the operating mode for digital output 51 / 52. The "Follow DO 41 / 42, 90° Shift, 180° Shift" operating
modes are only available if digital output 51 / 52 has been configured as a pulse output.
— Off: Digital output deactivated.
— Logic: Digital output functions as binary output (for function see parameter "„...Setup Logic Output").
— Follow DO 41 / 42: Digital output 51 / 52 operates according to the pulses from digital output 41 / 42. The
function depends on the setting for the parameter "Outp. Flow Direction".
— 90° Shift: 90° phase-shifted output of the same pulses as for digital output 41 / 42.
— 180° Shift: 180° phase-shifted output of the same pulses as for digital output 41 / 42.
Default setting: Logic.
Outp. Flow Direction
Selection of flow direction in which the pulse / frequency output issues the selected process value.
The parameter is only available if Follow DO 41 / 42 has been configured for digital output 51 / 52 in parameter
"Mode".
— No pulses are issued if "Forward & Reverse" is selected. Only digital output 41 / 42 is active.
— When "Forward" is selected, pulses for forward flow are issued at digital output 41 / 42 and pulses for reverse
flow at digital output 51 / 52.
— When "Reverse" is selected, pulses for reverse flow are issued at digital output 41 / 42 and pulses for forward
flow at digital output 51 / 52.
...Setup Logic Output Selection of submenu "...Setup Logic Output " using.
Only available if "ModeLogic" has been selected.
...Alarm Config Selection of submenu "...Alarm Config " using.
Only available if "ModeLogic" has been selected.
