62 OI/FEP610/FEH610-EN Rev. B | ProcessMaster FEP610, HygienicMaster FEH610
Menu / parameter Description
Diagnostics / ...Diagnosis Control / ...Noise Check
Start Noise Check Start the "Noise Check" function using .
Power Spectrum Current power spectrum.
Amplitude 1 Value Display the four highest amplitudes in the power spectrum.
Amplitude 2 Value
Amplitude 3 Value
Amplitude 4 Value
Frequency 1 Display the corresponding frequency to those four highest amplitudes in the power spectrum.
Frequency 2
Frequency 3
Frequency 4
Diagnostics / ...Diagnosis Control / ...Fingerprints
Tx Factory CMR The "fingerprint" database allows to compare the values at the time of factory calibration with the currently recorded
values. Errors in the integrity of the "Tx Factory 1m/s" device can be detected at an early stage.
Corrective actions can be taken.
Tx Factory 1m/s
Tx Factory 10m/s
Start Tx Customer FP Create the manual fingerprint for the transmitter using .
Tx Customer CMR The manual fingerprint is created on site prior to verification of the transmitter.
Use the parameter "Start Tx Customer FP" to create the the manual fingerprint.
Tx Customer 1m/s
Tx Customer 10m/s
Diagnostics / ...Diagnosis Values
All values in this menu are for information / service purposes only.
Inhouse Temperature Indicates temperature inside the Transmitter housing.
Inhouse Temp MaxPeak
Inhouse Temp MinPeak
Driver Current Indicates Sensor Coil drive current.
Signal Region on ADC Indicates the measuring signal within the AD-converter Input.
(-100% …. +100%)
Coil DAC Preset Indicates DA-converter for coil drive.
DC Feedback DAC DA-converter feedback value.
ADC Errors AD-converter errors.
Device Restart Count Numbers of device restarts (Boots).
