92 FEP630, FEH630 ELECTROMAGNETIC FLOWMETER | OI/FEP630/FEH630-EN REV. D
… 8 Operation
… Parameter descriptions
Menu / parameter Description
Input/Output / ...Dig.Out 51/52 / ...Setup Logic Output
Logic Output Action Selection of binary output function.
See description ‘„Input/Output / ...Dig.Out 41/42 / ...Setup Logic Output’.
Active Mode Select switching properties for the binary output.
• Active High: Normally open
• Active Low: Normally closed
Default setting: Active High.
Input/Output / ...Dig.Out 51/52 / ...Alarm Config
General Alarm Selection of error messages signaled via the binary output 51 / 52.
Only if the parameter ‘Logic Output Action’ is set to Alarm Signal.
Qv Volumeflow Max
Qv Volumeflow Min
EPD
TFE
Gas Bubble
Conductivity
Sensor Temperature
In house Temp
Input/Output / ...Dig.Out V1/V2
Input/Output / ...Dig. Out V3/V4
Mode Selection of operating mode for the digital output V1 / V2 or V3 / V4.
• Off: Digital output deactivated.
• Logic: Digital output functions as binary output (for function see parameter ‘...Setup Logic Output’).
The digital outputs V1 / V2 and V3 / V4 are only available if the corresponding plug-in cards are present!
...Setup Logic Output Selection of submenu ‘...Setup Logic Output’ using .
Only available if ‘Mode / Logic’ has been selected.
...Alarm Config Selection of submenu ‘...Alarm Config’ using .
Only available if ‘Mode / Logic’ has been selected.
