Description DNP point
address
Event class UR enable Deadband Value range
Number of trips of other elements 9 3 1 1 0...65535
Number of AR shots (shot 1) initiated by
the trip signal from element 50P-1
10 3 1 1 0...255
Number of AR shots (shot 1) initiated by
the digital input signal
11 3 1 1 0...255
Number of AR shots (shot 1) initiated by
the pickup or trip signal from element 51P
12 3 1 1 0...255
Number of AR shots (shot 1) initiated by
the pickup or trip signal from element
51N
13 3 1 1 0...255
Number of AR shots (shot 2) initiated by
the trip signal from element 50P-1
14 3 1 1 0...255
Number of AR shots (shot 2) initiated by
the digital input signal
15 3 1 1 0...255
Number of AR shots (shot 2) initiated by
the pickup or trip signal from element 51P
16 3 1 1 0...255
Number of AR shots (shot 2) initiated by
the pickup or trip signal from element
51N
17 3 1 1 0...255
Number of AR shots (shot 3) initiated by
the trip signal from element 50P-1
18 3 1 1 0...255
Number of AR shots (shot 3) initiated by
the digital input signal
19 3 1 1 0...255
Number of AR shots (shot 3) initiated by
the pickup or trip signal from element 51P
20 3 1 1 0...255
Number of AR shots (shot 3) initiated by
the pickup or trip signal from element
51N
21 3 1 1 0...255
5.1.16.3. DNP 3.0 device profile
DNP V3.00
DEVICE PROFILE DOCUMENT
Vendor Name: ABB Oy, Distribution Automation, Vaasa, Finland
Device Name: REF610
Highest DNP Level Supported Device Function
For Requests l
b
Slave
For Responses l
b
Notable objects, functions, and/or qualifiers supported in addition to the Highest DNP Levels
Supported (the complete list is described in the attached table):
Additions to level 2 are marked as shaded in the implementation table
Maximum Data Link Frame Size (octets) Maximum Application Fragment Size (octets)
Transmitted 292 Transmitted 2048
Received 292 Received 2048
Maximum Data Link Re-tries: Maximum Application Layer Re-tries:
Configurable, range from 0 to 255 with
primary data link layer retransmission count
Configurable, range from 0 to 255 with
application layer retransmission count
106
REF610REF610
Feeder Protection Relay
Technical Reference Manual - ANSI Version
1MRS755535
