Description HR/IR address (.bit) DI/Coil bit
address
Writeable Value
range
Comment
SO1 CD 413.07 72
SO2 413.08 73 0/1 1 = activated
SO2 CD 413.09 74
SO3 413.10 75 0/1 1 = activated
SO3 CD 413.11 76
SO4 413.12 77 0/1 1 = activated
SO4 CD 413.13 78
SO5 413.14 79 0/1 1 = activated
O5 CD 413.15 80
DI1 414.00 81 0/1 1 = activated
DI1 CD 414.01 82
DI2 414.02 83 0/1 1 = activated
DI2 CD 414.03 84
DI3 414.04 85 0/1 1 = activated
DI3 CD 414.05 86
DI4 414.06 87 0/1 1 = activated
DI4 CD 414.07 88
DI5 414.08 89 0/1 1 = activated
DI5 CD 414.09 90
Disturbance recorder 414.10 91 0/1 1 = triggered
0 = cleared
Disturbance recorder CD 414.11 92
HMI Setting password 414.12 93 0/1 1 = opened
0 = closed
HMI Setting password CD 414.13 94
IRF 414.14 95 0/1 1 = activated
IRF CD 414.15 96
Warning 415.00 97 0/1 1 = activated
Warning CD 415.01 98
SPA event overflow 415.02 99
SPA event overflow CD 415.03 100 Only the CD
bit will be
activated in
case of
overflow.
HMI Communication password 415.04 101 0/1 1 = opened
0 = closed
HMI Communication password CD 415.05 102
