ABB REG650 - Page 530

Name Values (Range) Unit Step Default Description
SetLED02 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 2
TrigDR03 Off
On
- - Off Trigger operation On/Off
SetLED03 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 3
TrigDR04 Off
On
- - Off Trigger operation On/Off
SetLED04 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 4
TrigDR05 Off
On
- - Off Trigger operation On/Off
SetLED05 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 5
TrigDR06 Off
On
- - Off Trigger operation On/Off
SetLED06 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 6
TrigDR07 Off
On
- - Off Trigger operation On/Off
SetLED07 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 7
TrigDR08 Off
On
- - Off Trigger operation On/Off
SetLED08 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 8
TrigDR09 Off
On
- - Off Trigger operation On/Off
SetLED09 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 9
TrigDR10 Off
On
- - Off Trigger operation On/Off
SetLED10 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 10
Table continues on next page
Section 14 1MRK 502 048-UEN A
Monitoring
524
Technical manual
