Name Values (Range) Unit Step Default Description
TrigDR11 Off
On
- - Off Trigger operation On/Off
SetLED11 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 11
TrigDR12 Off
On
- - Off Trigger operation On/Off
SetLED12 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 12
TrigDR13 Off
On
- - Off Trigger operation On/Off
SetLED13 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 13
TrigDR14 Off
On
- - Off Trigger operation On/Off
SetLED14 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 14
TrigDR15 Off
On
- - Off Trigger operation On/Off
SetLED15 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 15
TrigDR16 Off
On
- - Off Trigger operation On/Off
SetLED16 Off
Start
Trip
Start and Trip
-
- Off Set LED on HMI for binary channel 16
FunType1 0 - 255 - 1 0 Function type for binary channel 1 (IEC
-60870-5-103)
InfNo1 0 - 255 - 1 0 Information number for binary channel 1
(IEC -60870-5-103)
FunType2 0 - 255 - 1 0 Function type for binary channel 2 (IEC
-60870-5-103)
InfNo2 0 - 255 - 1 0 Information number for binary channel 2
(IEC -60870-5-103)
FunType3 0 - 255 - 1 0 Function type for binary channel 3 (IEC
-60870-5-103)
InfNo3 0 - 255 - 1 0 Information number for binary channel 3
(IEC -60870-5-103)
FunType4 0 - 255 - 1 0 Function type for binary channel 4 (IEC
-60870-5-103)
InfNo4 0 - 255 - 1 0 Information number for binary channel 4
(IEC -60870-5-103)
