DirModeSelx: The directional mode of step x. Possible settings are Disabled/Non-
directional/ Forward/Reverse.
Characteristn: Selection of time characteristic for step n. Definite time delay and different
types of inverse time characteristics are available according to
Table 10 . Step 2 and 3 are
always definite time delayed.
Table 10: Inverse time characteristics
Curve name
ANSI Extremely Inverse
ANSI Very Inverse
ANSI Normal Inverse
ANSI Moderately Inverse
ANSI/IEEE Definite time
ANSI Long Time Extremely Inverse
ANSI Long Time Very Inverse
ANSI Long Time Inverse
IEC Normal Inverse
IEC Very Inverse
IEC Inverse
IEC Extremely Inverse
IEC Short Time Inverse
IEC Long Time Inverse
IEC Definite Time
ASEA RI
RXIDG (logarithmic)
The different characteristics are described in the Technical manual.
Pickupx: Operation phase current level for step x given in % of IBase.
tx: Definite time delay for step x. Used if definite time characteristic is chosen.
: Time multiplier for inverse time delay for step n.
TDn: Time multiplier for inverse time delay for step n.
IMinn: Minimum operate current for step n in % of IBase. Set IMinn below Pickupx for
every step to achieve ANSI reset characteristic according to standard. If IMinn is set above
Pickupx for any step the ANSI reset works as if current is zero when current drops below
IMinn.
1MRK 506 334-UUS A Section 7
Current protection
193
Application manual
