Name Values (Range) Unit Step Default Description
OverTrigLe36 0 - 5000 % 1 200 Over trigger level for analog channel 36 in
% of signal
NomValue37 0.0 - 999999.9 - 0.1 0.0 Nominal value for analog channel 37
UnderTrigOp37 Off
On
- - Off Use under level trigger for analog channel
37 (on) or not (off)
UnderTrigLe37 0 - 200 % 1 50 Under trigger level for analog channel 37
in % of signal
OverTrigOp37 Off
On
- - Off Use over level trigger for analog channel
37 (on) or not (off)
OverTrigLe37 0 - 5000 % 1 200 Over trigger level for analog channel 37 in
% of signal
NomValue38 0.0 - 999999.9 - 0.1 0.0 Nominal value for analog channel 38
UnderTrigOp38 Off
On
- - Off Use under level trigger for analog channel
38 (on) or not (off)
UnderTrigLe38 0 - 200 % 1 50 Under trigger level for analog channel 38
in % of signal
OverTrigOp38 Off
On
- - Off Use over level trigger for analog channel
38 (on) or not (off)
OverTrigLe38 0 - 5000 % 1 200 Over trigger level for analog channel 38 in
% of signal
NomValue39 0.0 - 999999.9 - 0.1 0.0 Nominal value for analog channel 39
UnderTrigOp39 Off
On
- - Off Use under level trigger for analog channel
39 (on) or not (off)
UnderTrigLe39 0 - 200 % 1 50 Under trigger level for analog channel 39
in % of signal
OverTrigOp39 Off
On
- - Off Use over level trigger for analog channel
39 (on) or not (off)
OverTrigLe39 0 - 5000 % 1 200 Over trigger level for analog channel 39 in
% of signal
NomValue40 0.0 - 999999.9 - 0.1 0.0 Nominal value for analog channel 40
UnderTrigOp40 Off
On
- - Off Use under level trigger for analog channel
40 (on) or not (off)
UnderTrigLe40 0 - 200 % 1 50 Under trigger level for analog channel 40
in % of signal
OverTrigOp40 Off
On
- - Off Use over level trigger for analog channel
40 (on) or not (off)
OverTrigLe40 0 - 5000 % 1 200 Over trigger level for analog channel 40 in
% of signal
