Table 499: SMAI_20_1 Non group settings (advanced)
Name Values (Range) Unit Step Default Description
Negation Off
NegateN
Negate3Ph
Negate3Ph+N
-
- Off Negation
MinValFreqMeas 5 - 200 % 1 10 Limit for frequency calculation in % of
UBase
Even if the AnalogInputType setting of a SMAI block is set to
Current, the MinValFreqMeas setting is still visible. This means that
the minimum level for current amplitude is based on UBase. For
example, if UBase is 20000, the minimum amplitude for current is
20000 * 10% = 2000. This has practical affect only if the current
measuring SMAI is used as a frequency reference for the adaptive
DFT. This is not recommended, see the Setting guidelines.
Table 500: SMAI_20_12 Non group settings (basic)
Name Values (Range) Unit Step Default Description
GlobalBaseSel 1 - 6 - 1 1 Selection of one of the Global Base Value
groups
DFTReference InternalDFTRef
DFTRefGrp1
DFTRefGrp2
DFTRefGrp3
DFTRefGrp4
DFTRefGrp5
DFTRefGrp6
DFTRefGrp7
DFTRefGrp8
DFTRefGrp9
DFTRefGrp10
DFTRefGrp11
DFTRefGrp12
External DFT ref
- - InternalDFTRef DFT reference
ConnectionType Ph-N
Ph-Ph
- - Ph-N Input connection type
AnalogInputType Voltage
Current
- - Voltage Analog input signal type
Table 501: SMAI_20_12 Non group settings (advanced)
Name
Values (Range) Unit Step Default Description
Negation Off
NegateN
Negate3Ph
Negate3Ph+N
-
- Off Negation
MinValFreqMeas 5 - 200 % 1 10 Limit for frequency calculation in % of
UBase
