CHAPTER 23. LIVE INSTRUMENT REFERENCE 402
with low resonance settings. The 24 dB lter modes attenuate the ltered frequencies to a
much greater degree than the 12 dB modes. The Ladder and SVF lters provide additional
lter architectures.
Filter Frequency (Freq) This denes the center or cutoff frequency of the lter. Note that
the resulting frequency may also be modulated by note velocity and by the lter envelope.
Filter Resonance (Res) This denes the resonance around the lter frequency of the lowpass
and highpass lters, and the width of the bandpass and notch lters.
Envelope / Filter Switches These switches toggle the display between the lter's envelope
and its frequency response.
Filter Frequency<Velocity (Freq<Vel) Filter frequency is modulated by note velocity ac-
cording to this setting.
Filter Frequency<Key (Freq<Key) Filter frequency is modulated by note pitch according
to this setting. A value of 100% means that the frequency doubles per octave. The center
point for this function is C3.
Filter Envelope Rates<Velocity (Time<Vel) This parameter exists for lter, pitch, LFO and
volume envelopes. It is therefore listed in the section on envelopes.
Filter Frequency<Envelope (Envelope) Filter frequency is modulated by the lter envelope
according to this setting. A value of 100% means that the envelope can create a maximum
frequency shift of approximately 9 octaves.
Shaper This chooser selects the curve for the lter's waveshaper.
Drive This boosts or attenuates the signal level being sent to the waveshaper.
Dry/Wet This adjusts the balance between the dry signal and the signal processed by the
waveshaper.
LFO Shell and Display
LFO On This turns the LFO (low-frequency oscillator) on and off. Turning it off when it is
unused saves some CPU power.
