6. I/O ports A96G174/A96S174 User’s manual
48
P0FSRL (Port 0 Function Selection Low Register): D2H
7
6
5
4
3
2
1
0
P0FSRL7
P0FSRL6
P0FSRL5
P0FSRL4
P0FSRL3
P0FSRL2
P0FSRL1
P0FSRL0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
P0FSRL[7:6]
P03 Function Select
P0FSRL7
P0FSRL6
Description
0
0
I/O Port
0
1
Reserved
1
0
T0O/PWM0O Function
1
1
AN5 Function
P0FSRL[5:4]
P02 Function Select
P0FSRL5
P0FSRL4
Description
0
0
I/O Port(EINT0 function possible when
input)
0
1
SCL Function
1
0
Reserved
1
1
Reserved
P0FSRL[3:2]
P01 Function Select
P0FSRL3
P0FSRL2
Description
0
0
I/O Port
0
1
SDA Function
1
0
Reserved
1
1
AN4 Function
P0FSRL[1:0]
P00 Function Select
P0FSRL1
P0FSRL0
Description
0
0
I/O Port(EC0 function possible when input)
0
1
SS Function
1
0
Reserved
1
1
AN3 Function
