A96G174/A96S174 User’s manual 6. I/O ports

P0FSRH (Port 0 Function Selection High Register): D3H

P0FSRH7

P0FSRH6

P0FSRH5

P0FSRH4

P0FSRH3

P0FSRH2

P0FSRH1

P0FSRH0

R/W

Initial value: 00H

P0FSRH[7:6]

P07 Function Select

P0FSRH7

P0FSRH6

Description

I/O Port

RXD/MISO Function

T1O/PWM1O

AN9 Function

P0FSRH[5:4]

P06 Function Select

P0FSRH5

P0FSRH4

Description

I/O Port

TXD/MOSI Function

PWM1OB

AN8 Function

P0FSRH[3:2]

P05 Function Select

P0FSRH3

P0FSRH2

Description

I/O Port

SCK Function

Reserved

AN7 Function

P0FSRH[1:0]

P04 Function Select

P0FSRH1

P0FSRH0

Description

I/O Port

Reserved

T2O/PWM2O

AN6 Function
