Accu-Chek ACTIVE User Manual

19
Steps before testing
2.4 Performing a display check
Press at the same time
for more than 3 seconds
You can check if all of the display elements are
properly displayed, by carrying out a full display
check.
1 With the meter turned off, press the M and S
buttons at the same time until the meter is
switched on automatically (more than 3 sec-
onds).

Accu-Chek ACTIVE Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1 - 2 μL
Test Time	5 seconds
Memory Capacity	500 results
Display Type	LCD
Automatic Coding	Yes
Blood Sample	Capillary whole blood
Dimensions	97.8 x 46.8 x 19.1 mm
Battery Type	1 x 3V lithium battery (type CR2032)
Battery Life	Approximately 1000 tests
Data Transfer	Via infrared (IR) to computer
Operating Conditions	8-42°C, 10-85% RH
