Accu-Chek ACTIVE User Manual

83
Cleaning the meter
8.1 External parts
If the case of the meter or the display is dirty:
1 Wipe away any dirt using a cloth lightly mois-
tened with cold water or 70 % ethanol.
8.2 Test strip guide and measuring
window
You only need to clean the test strip guide and
measuring window
if you notice that the test strip guide or the meas-

uring window located beneath the cover are visibly
dirty,
if the error message

or is displayed.
A dirty measuring window may be the cause.

Accu-Chek ACTIVE Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1 - 2 μL
Test Time	5 seconds
Memory Capacity	500 results
Display Type	LCD
Automatic Coding	Yes
Blood Sample	Capillary whole blood
Dimensions	97.8 x 46.8 x 19.1 mm
Battery Type	1 x 3V lithium battery (type CR2032)
Battery Life	Approximately 1000 tests
Data Transfer	Via infrared (IR) to computer
Operating Conditions	8-42°C, 10-85% RH
