Accu-Chek ACTIVE User Manual

36
Testing blood glucose
Applying blood with the test strip outside the meter
When the test strip and the ashing blood drop
symbols are displayed:
1 Remove the test strip from the meter.
The test strip and blood drop symbols ash in the
display. Now you have approx. 20 seconds to apply
blood to the test strip and to re-insert it into the
meter. If you do not re-insert the test strip within this
time, the meter displays the error message
.

Accu-Chek ACTIVE Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1 - 2 μL
Test Time	5 seconds
Memory Capacity	500 results
Display Type	LCD
Automatic Coding	Yes
Blood Sample	Capillary whole blood
Dimensions	97.8 x 46.8 x 19.1 mm
Battery Type	1 x 3V lithium battery (type CR2032)
Battery Life	Approximately 1000 tests
Data Transfer	Via infrared (IR) to computer
Operating Conditions	8-42°C, 10-85% RH
