Accu-Chek ACTIVE User Manual

34
Testing blood glucose
Applying blood with the test strip in the meter
When the test strip and the ashing blood drop
symbols are displayed, you have approx. 90 seconds
to apply blood to the test strip. After this the meter
turns itself off.
1 Prick the side of a ngertip with your lancing
device.
2 Encourage a drop of blood to form by gently
massaging your nger towards the ngertip.
3 Apply the drop of blood to the centre of the
orange eld and then remove your nger from
the test strip.

Accu-Chek ACTIVE Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1 - 2 μL
Test Time	5 seconds
Memory Capacity	500 results
Display Type	LCD
Automatic Coding	Yes
Blood Sample	Capillary whole blood
Dimensions	97.8 x 46.8 x 19.1 mm
Battery Type	1 x 3V lithium battery (type CR2032)
Battery Life	Approximately 1000 tests
Data Transfer	Via infrared (IR) to computer
Operating Conditions	8-42°C, 10-85% RH
