Testing blood glucose
While the test result is displayed:
1 Press the S button repeatedly until the desired
ag is displayed.
The ags appear in the following order:
1. Before meals
2. After meals
3. General
4. Control
If you decide to not ag the test result, press the S
button repeatedly until no further symbol is dis-
played.
No ag
Press briey
Control (bottle)
General (asterisk)
After meals
(apple core)
Before meals (apple)

Accu-Chek ACTIVE Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1 - 2 μL
Test Time	5 seconds
Memory Capacity	500 results
Display Type	LCD
Automatic Coding	Yes
Blood Sample	Capillary whole blood
Dimensions	97.8 x 46.8 x 19.1 mm
Battery Type	1 x 3V lithium battery (type CR2032)
Battery Life	Approximately 1000 tests
Data Transfer	Via infrared (IR) to computer
Operating Conditions	8-42°C, 10-85% RH
