Accumet AP75 - P4.3 Selecting Automatic or Manual Temperature Compensation

33
P4.3 Selecting Automatic or Manual Temperature Compensation
This feature lets you select between Automatic Temperature Compensation (ATC)
and Manual Temperature Compensation. Meter default is ATC.
From measurement mode
1. Press Setup key to enter Set Up mode.
2. Press the ▲ and ▼ keys to scroll
through subgroups until you view
parameter P4.0.
See figure
3. Press the ENTER key three times to
select parameter 4.3. The upper display
shows “ATC” and the lower display
shows “P4.3”.
See figure
4. Press the ENTER key again. The upper
display shows “ATC” and the lower
display shows “YES” or “NO”.
See figure
5. Press the ▲ and ▼ keys to select the
Automatic Temperature Compensation
on of off.
• YES = ATC on
• NO = ATC off
6. Press the ENTER key to confirm
selection and to return to the subgroup
menu. Press the CAL/MEAS key to
return to measurement mode.
