Acer P5271 - Disassemble Lamp Module

P5271/P5290/P5390W/P5271i Condential
2-2
2. Pull upword the Lamp Cover Module
slightly (as blue arrows point).
3. Loosen 3 screws (as red circle) on the
Lamp Module.
4. Take off the Lamp Module.
2-2 Disassemble Lamp
Module
1. Push the two clips (as red square) as
yellow arrows point on the left/right side
of the projector.
Left side of projector
Right side of projector
