ACO 3116 - Supplementary References; Indicated Value to AC Output Correlation

― 37 ―
Reference 2
Relation between indicated value and AC output
The relation between full scale indicated value and AC output voltage at output terminal, in
each Measurement mode and Range, are shown as in the following table.
Measurement
mode
Range Data mode
Full scale
indicating value
Output Voltage
（Vrms）
ACC
200 m/s
２
RMS 200.0
1.000
EQ
peak
282.8
PEAK
28
2.8
20 m/s
２
RMS 20.00
EQpeak
28.28
PEAK
28.28
VEL
200 mm/s
RMS 200.0
EQpeak
282.8
PEAK
282.8
20 mm/s
RMS 20.00
EQpeak 28.28
PEAK
28.28
DISP
2000μm
RMS
707
EQpeak 1000
EQ p
-
p
2000
PEAK
1000
200μm
RMS 70.7
EQpeak
100.0
EQ p
-
p
200.0
PEAK 100.0
Indicated value and output voltage are in linear relationship.
ex1) In the case of indicated value 10 m/s
２
RMS in Range “ACC 20m/s
２
:
Output voltage＝10（m/s
２
）÷20（m/s
２
）×1（Vrms）＝0.500（Vrms）
ex2) In the case of indicated value 5 m/s
２
EQpeak in Range “ACC 20m/s
２
:
Output voltage＝5（m/s
２
）÷28.28（m/s
２
）×1（Vrms）＝0.177（Vrms）
ex3) In the case of indicated value 15 μm RMS in Range “DISP 200μm:
Output voltage＝15（μm）÷70.7（μm）×1（Vrms）＝0.212（Vrms）
Caution
0v
(Overload) shall be checked and
adjusted
with
the acceleration mode (ACC) and
at the display of mode of
Peak.
Even if
0v
(Overload) is not indicated at the
velocity (VEL) mode or displacement (DISP) mode, there can be cases where the value
exceeds the measurement range.
To adjust the range at velocity (VEL) mode, when the acceleration (ACC) is at 20 m/s
2
range,
set velocity (VEL) to 20 mm/s range, and when the acceleration (ACC) is at 200 m/s
2
range,
set velocity (VEL) to 200 mm/s.
To adjust the range at displacement (DISP) mode, when the acceleration (ACC) is at 20 m/s
2
range, set displacement (DISP) to 200μm range, and when the acceleration (ACC) is at 200
m/s
2
range, set displacement (DISP) to 2000μm.
(See page 40)
